CPM2322

6
ITEM PART
NO NUMBER QTY PART DESCRIPTION
83 4503700 4 HI-COLLARLOCK WASHER, M16, DIN 7980
84 3015500 1 LUBE FITTING, 1/8″ NPT
90 3915603 1 HEX HEAD CAP SCREW, M20 X 55
91 4509500 1 HEX NUT, M20
92 3919100 1 LOCK WASHER, M20
100 4654700 2 SPHERICAL BEARING
110 5724902 1 GEARBOX FRONT LINER – 3022
111 4615300 6 CAP SCREW M10 X 1.5 HEX HD X 16 MM L
112 4507501 6 LOCK WASHER, M10, SS
120 5725000 1 PINION BEARING HOUSING COVER
121 4602600 6 CAP SCREW M8 X 1:25 HEX HD X 16 MM L
130 0554500 1 ADAPTER RING – FEED CHUTE
140 5606303 2 PELLET CHAMBER LATCH
143 4506500 4 FLAT WASHER, M16
144 3915308 2 SET SCREW M16 X 2 SKT HD X 20 MM LG
145 3902515 2 HEX HEAD CAP SCREW, 5/8″ NC X 3 3/4″
146 3906906 2 FLAT WASHER, 5/8″
147 3186100 2 LATCH SPRING
148 3904905 2 HEX NUT, 5/8″ NC FLEXLOC
141 3912804 4 SCR CAP M16 X 30 LG HEX HD
142 3915403 4 LOCK WASHER, M16
