CPM3022 DIE CARRIER COMPONENTS (4 PCS CLAMP)

screenshot_1691985839
8096304 QUILL FLANGE ASSEMBLY
5228705 DIE DRIVING KEY (M16 X 2 TAP)
3915303 NYLOC SOCKET HD SET SCREW, M16 X 30
5228752 NYLON PLUG
5120659 QUILL WEAR INSERT
4672401 HELICOIL INSERT, SCREW LOCK TYPE
3375203 DOWEL PIN 8MM DIA. X 18MM LG SS
4676300 SOCKET HD CAP SCREW, M20 X 50MM LG SKT
0711800 DIE CLAMP SEGMENT- 4 PCS
0694000 NUT, ACME DIE CLAMP
0693900 SLEEVE, ACME DIE CLAMP
0693700 THRUST WASHER
4631108 RETAINING RING
4672400 HELICOIL INSERT M24 X 3 X 24
0693800 HOLD DOWN BOLT
3430811 DISC SPRING
0729300
CLAMP/JACK BOLT
4673200 BELLEVILLE WASHER, M24 ZINC
DIE
5130112 FEED CONE
8052601A ELASTIC FEED CONE FASTENER ASSMBLY
5227203 HEX HEAD SHOULDER SCREW
3244700 BELLVILLE SPRING
5227251 RETAINING WASHER
3311000 RETAINING RING
