PL, HOIST, DIE MAN/PNEU 7900 UNIVERSAL
10 0721000 1 Trolley,Die Hoist Model 7900
20 0407400 1 Roller,Die Hoist
30 3022302 4 Bushing,Bearing
40 3907203 6 Washer,Flat ø 1″ Steel Standard
50 5230900 1 Pin,Roller
60 3010600 2 Washer,Retaining
70 0405800 4 Roller,Die Hoist
71 0405802 1 Roller – Die Hoist
80 3219500 5 Bearing
81 3907010 5 Washer,
82 3905201 5 Nut,Hex Jam
90 3276900 5 Washer,Retaining
100 5238602 5 Spacer, Brg – 7800/8000
110 3221800 5 Lube Fitting – Alemite
120 SEE SPECS**76 1 DIE HOIST WINCH
121 4537000 4 Screw,
122 3915403 4 Washer,
123 4504700 4 Nut,Hex
130 0644600 1 Cable,Die Hoist 9000
140 3298000 1 Nut,Toggle
150 3297901 1 Knob,Hand
160 0720801 1 Bar,Spreader Die Hoist
170 3471201 2 Pin,
175 3471202 2 Pin,
180 0410400 2 Roller,Die Hoist
190 5158902 2 Roller Pin
200 3099601 2 Cotter Pin
205 8143590 1 Assy, Utility Hook
205.01 0720891 1 Bracket, Hook Model 7900 Pelle T Mill
205.02 3426001 1 Hook, Threaded Shank-Utility
210 SEE SPECS**19 1 DIE LIFTING PLATE
220 SEE SPECS**20 1 ROLLER HOIST ASSEMBLY
