Manual press unit, clamped lubricated centrally (Part 1)
| DPHE-80217-810 | Central lubrication unit, assembly |
| DPHD-80280-810 | Grease distribution holder |
| DPHD-80246-810 | Pressure intensifying module |
| UNN -12026-028 | Shaft nut KM-30, M150x2.0 |
| UXN -14002-006 | Washer D 40/20.5×8 |
| UNE -26311-014 | Proximity switch, inductive |
| UNN -24049-650 | Coupling sleeve, open G 1/4″ |
| UNN -24049-652 | Coupling nipple D 7.6 |
| UXN -14002-007 | Washer D 36/16.5×8 |
| UNN -10010-232 | Hexagon head bolt M16x30 |
| UNN -24037-008 | Screw-in union D 8 G 1/4″ |
| UNS -16125-002 | Manual slide valve G 1/4″ |
| MDDM-40090-010 | Pneumatic cock sheet metal |
| UXE -24002-111 | Cable socket M12x1 with cable L = 10000 |
| UXE -24002-150 | Unlocking protector for M12 |
| UNN -22006-005 | Hose clamp D 11-13 |
| DPHD-95220-520 | Coupling hose |
| DPHD-80380-810 | Strain relief bracket at top |
| DPHD-80381-810 | Strain relief bracket at bottom |
| UNN -10008-150 | Hexagon head bolt M6x10 |
| UNN -14000-005 | Washer D 8.4/16×1.6 |
| UNN -10008-212 | Hexagon head bolt M8x16 |
| UNN -22008-201 | Crimp sleeve 6/4×6 |
| UNN -14002-001 | Washer D 6.4/18×1.6 |
| DPHD-95220-600 | Wire rope |
