LA MECCANICA 800

8
Pos. N.P.M. Code – Codice Name of parts
0 1 305.138.0 Safety locking groupe bassembly
1 1 A.CP1.001- Spacer rod main door locking
2 1 Catch
3 1 Packing MERKEL P7-16
4 1 Bush
5 1 Pin
6 1 EMEXCKD39H2P16EX Safety microswitch
7 1 Microswitch flange
8 1 Safety locking groupe body
9 1 Spring
10 1 Pneumatic cylinder flange
11 1 Pneumatic cylinder
12 1 EMEXCKD39H2P16EX Safety microswitch
13 2 Washer
14 2 Hinge shaft
15 2 Retainig ring D40 UNI 7435
