10 0705300 1 Liner,Front Gearbox
11 4504601 4 Screw,Hex Head Cap
12 3915402 4 Washer,Spring
13 0727700 4 Washer,Flat
15 0705350 1 Liner,Inner Gearbox
16 4605300 6 Screw,Hex Head Cap
17 3915001 6 Washer,Spring
20 0708551 1 Bracket,Mounting
21 4500300 4 Screw,Hex Head Cap
22 3919100 4 Washer,Spring
23 4543200 2 Screw,Hex Head Cap
24 3915403 2 Washer,Spring
25 5767401 4 Shim,Hinge Support
30 0728400 2 Bar,Spacer
40 0511204 2 End,Hinge Rod
45 3409900 4 Locknut
50 4654701 2 Bearing,Roller Spherical
51 3915506 1 Screw,Hex Head Cap
52 3917800 1 Nut,Hex
53 3916800 1 Washer,Spring
54 3334900 1 Caplug BPF 7/8
60 0727300 1 Bracket,Mounting
61 4500300 4 Screw,Hex Head Cap
62 3919100 4 Washer,Spring
63 4543200 2 Screw,Hex Head Cap
64 3915403 2 Washer,Spring
65 3915302 2 Set Screw,Hex Socket
66 4504700 2 Nut,Hex
70 3219500 1 Bearing
71 3905201 1 Nut,Hex Jam
72 3907002 1 Washer,Lock
73 3221800 1 Lube Fitting – Alemite
80 8140401 2 Latch,Assy
80.01 0710701 1 Pin,U-Bolt
80.02 0709701 1 Clevis
80.03 0710501 1 Handle,Latch
80.04 3375204 1 Pin,Dowel
80.06 7233560 1 Plate,Clamp
80.07 4575300 2 Washer,Flat
80.08 3234003 2 Spring,Compression
80.09 3904709 2 Nut,Hex Nylock
80.10 3926902 4 Washer,Flat
81 4505100 8 Screw,Hex Head Cap
82 4502700 Washer,Spring
83 4599000 Washer,Flat
90 0713400 Cam,Door Alignment 1
91 4505100 Screw,Hex Head Cap
92 4502700 Washer,Spring
93 4599000 Washer,Flat
94 3134602 Pin,Roll 2
95 0717000 Shim,Pack 3
100 0640506 Bar,Hinge 1
101 3912603 Screw,Hex Head Cap
102 4502700 Washer,Spring 8
105 5767301 Shim,Hinge Bar 2
111 4504900 8 Screw,Hex Head Cap
112 4505201 8 Washer,Flat
113 3915001 8 Washer,Spring
114 4509101 8 Nut,Hex
115 3772800 2 Handle,Pull
116 4676202 4 Screw,Socket Head Cap
117 4598801 4 Washer,Spring
121 4506402 16 Nut,Hex
130 8091811 2 Post,Knife Assy
130.01 5257201 1 Housing,Knife Post
130.02 5764600 1 Bushing
130.03 3015500 1 Nipple,Grease
130.04 5257301 1 Key,Knife Post
130.05 5257400 1 Stop,Knife Post
130.06 5257001 1 Post,Knife
130.07 5571601 1 Handle
130.08 16 0 Not applicable
130.09 5571602 1 Handle
130.10 4664400 1 Seal,Lip Knife Post
130.11 5166201 1 Handle,Knife Post
130.12 4668500 1 Screw,Socket Head Cap
131 4553800 6 Screw,Socket Head Cap
132 4507400 6 Washer,Flat
135 78 0 See Page197 Blade, Knife
136 4535201 4 Screw,Hex Head Cap
137 4507501 4 Washer,Spring
138 4507403 4 Washer,Flat
139 4506402 4 Nut,Hex
140 0438351 2 Plate,Knife Post
141 4504900 8 Screw,Hex Head Cap
142 4505201 8 Washer,Flat
181 4545300 4 Screw,Hex Head Cap
182 4508000 4 Washer,Flat
183 4535700 2 Screw,Hex Head Cap
184 4540900 2 Washer,Flat
185A 0709121A 1 2 Pieces Pellet Chamber
185B 0709121B 1 Knife Retaining Plate
185C 0709121C 1 Knife Retaining Support Bracket
